撒布车液压油箱的使用与维护保养
来源:https://www.sddhfjx.com/ 日期:2023-07-03
液压油箱位于前仓内,配装于前仓仓壁上,主要起到降温散热的作用。下面水泥撒布车出租人员为你讲解一番:
The hydraulic oil tank is located in the front compartment and is installed on the wall of the front compartment, mainly for cooling and heat dissipation. Below, the rental personnel of the cement spreader truck will explain to you:
1、液压油观察孔
1. Hydraulic oil observation hole
液压油观察孔上有红点标注,一般液压油不要超过红点即可。
There is a red dot mark on the hydraulic oil observation hole. Generally, hydraulic oil should not exceed the red dot.
2、手、自动切换开关
2. Manual and automatic switching switch
一般情况下处于自动常开位置,自动状态下散热风扇会自动开启,手动状态下散热风扇为常开。
Generally, when it is in the automatic normally open position, the Computer fan will automatically start under the automatic state, and the Computer fan is normally open under the manual state.
3、保险
3. Insurance
打开旋转开关后即可看到内部的保险晶体管
After turning on the rotary switch, you can see the internal fuse transistor
4、散热风扇
4. Computer fan
当液压油油温45℃时散热器会自动开启降温,温度低于45℃时散热风扇自动停止。
When the hydraulic oil temperature is 45 ℃, the radiator will automatically start to cool down, and when the temperature is lower than 45 ℃, the Computer fan will automatically stop.
5、溢流管
5. Overflow pipe
主要起到液压油溢流的作用
Mainly plays a role in hydraulic oil overflow
平时使用的时候我们要注意以下几点:
When using it regularly, we should pay attention to the following points:
水泥撒布车出租
(1)、液压油的补加
(1) Hydraulic oil replenishment
液压系统所使用的液压油为46#高清洁抗压耐磨液压油,补加的时候要特别注意,一定要把加油口处的粉尘清理干净,并适量补加,不要超过观察孔处的红色点位,以免液压油加多了产生外溢。如有外溢,请不要用水清洗,可选择擦拭清理的方式处理。
The hydraulic oil used in the hydraulic system is 46 # high clean, pressure resistant, and wear-resistant hydraulic oil. Special attention should be paid when adding it. The dust at the oil filling port must be cleaned and an appropriate amount should be added, not exceeding the red dot at the observation hole, to avoid overflow caused by adding too much hydraulic oil. If there is any overflow, please do not use water to clean it. You can choose to wipe and clean it.
(2)、液压油箱的吹扫
(2) Purging of hydraulic oil tank
因工作环境特殊,粉尘量较大,液压油箱的散热片会沾附较多粉尘,粉尘的沾附会影响液压油油温的下降并增加散热风扇的运转时间。因此,油箱散热片需要定期吹扫,吹扫的时候气枪不要离散热片过近,以免碰伤散热片。
Due to the special working environment and large amount of dust, the radiator of the hydraulic oil tank will be stained with more dust, which will affect the drop of the hydraulic oil temperature and increase the running time of the Computer fan. Therefore, the fuel tank heat sink needs to be regularly purged, and the air gun should not be too close to the heat sink during purging to avoid damaging it.
(3)、溢流管
(3) Overflow pipe
溢流管可能会因工作环境或其他原因产生溢流,正常使用的时候可能会有部分师傅为了维持前仓的清洁选择在溢流管下方配装一个瓶子,此时应特别注意,溢流管的下端不能没入到瓶内的液压油内,以免瓶内不清洁的液压油因压力等原因回吸到油箱内,污染液压系统的清洁度,甚至产生相关的车辆故障。
The overflow pipe may overflow due to working environment or other reasons. During normal use, some workers may choose to install a bottle under the overflow pipe to maintain the cleanliness of the front compartment. At this time, special attention should be paid to the bottom of the overflow pipe not to fall into the hydraulic oil inside the bottle, to prevent the unclean hydraulic oil inside the bottle from being sucked back into the oil tank due to pressure or other reasons, which may contaminate the cleanliness of the hydraulic system, Even related vehicle malfunctions may occur.
(4)、液压油箱相关连接管件
(4) Hydraulic oil tank related connecting pipe fittings
液压油箱相关连接管件需要定期检查,查看有无松动现象,如有松动,及时复紧,以免产生液压油渗漏。
The relevant connecting fittings of the hydraulic oil tank need to be regularly inspected to see if there is any looseness. If there is looseness, it should be re tightened in a timely manner to avoid hydraulic oil leakage.
应特别注意,液压油箱散热风扇虽然会自动开启降温,但在使用过程中也会存在一定量的粉尘堆积,粉尘的堆积会影响散热片的散热效果,也会影响风扇的开启与关闭时间,影响着散热风扇的使用寿命。更多相关事项就来我们网站https://www.sddhfjx.com咨询吧!
Special attention should be paid to that although the Computer fan of the hydraulic oil tank will automatically turn on for cooling, there will also be a certain amount of dust accumulation in the use process. The accumulation of dust will affect the heat dissipation effect of the cooling fin, the opening and closing time of the fan, and the service life of the Computer fan. For more related matters, come to our website https://www.sddhfjx.com Consult!
